SMD Color Coding for Resistors having values less than 10

Resistors having values less than 10 are decoded by using the format XRY. Where X is the simple number ranging b/w 0-9 and  Y is the radix point. Just consider an example case where an SMD resistor has value: 4R6
smd-color-coding-for-resistors-having-values-less-than-10
Now 4R6 means,
4.6 ohms.

Other examples:
0R11 = 0.11 ohms
1R7 = 1.7 ohms
5R8 = 5.8 ohms

So that was all about SMD coding.
